6*6 100pcs 110g Disposable 100% Polyester Microfiber Electronic Cleanroom Cleaning Wipers
6*6 100pcs 110g Disposable 100% Polyester Microfiber Electronic Cleanroom Cleaning Wipers
Description:
Myesde cleanroom polyester microfiber wipe is constructed from 100% Polyester fiber which provides superior dimensional stability. The fabrics are knitted from microfiber yarns which are soft and designed for the most sensitive and critical cleaning applications. Sealed edge wipers are thermally sealed to prevent particle and fiber release. Excellent effect in cleaning surface particle and Superb absorbency to oil stain.
Applications:
- Cleaning and Polishing Stainless Steel Surface.
- Superior for spill control and general wiping in ISO Class 5 Cleanroom Facilities.
- Highest level of contamination control in critical processing applications.
- Oxidation, Metallization, CVD or Photolithography processes, medical device products, stencil and other print roll cleaning
applications, chamber cleaning and CMP processing.
Features and Benefits:
• Cleanroom laundered and packaged providing ultra low levels of ions and non volatile residues.
• Designed for use on abrasive surfaces. This wipe will not easily snag or abrade releasing articles and fibers into the process or environment.
• Excellent chemical resistance for compatibility with a variety of solutions.
• Individually lot coded for ease of trace-ability and quality control.
• Good absorption with water and solvents.Hold more
Technical Data:
Attribute; (units) | Value ** | Test Method | ||||
Basis weight; nominal (g/m2) | 112 | MSD-QI-QS-007 A0 | ||||
Absorbency in water | IEST-RP-CC004.3 | |||||
Intrinsic; (mL/g) | 2.52 | |||||
Extrinsic; (mL/m2) | 282.2 | |||||
Sorptive rate; (seconds) | 1 | IEST-RP-CC004.3 | ||||
Non-volatile residue, NVR | IEST-RP-CC004.3 | |||||
In deionized water; (g/m2) | 0.014 | |||||
In isopropanol; (g/m2) | 0.012 | |||||
Specific ions | IEST-RP-CC004.3 | |||||
Sodium; (ppm) | 0.012 | |||||
Chloride; (ppm) | 0.069 | |||||
Potassium; (ppm) | 0.057 | |||||
Particles, readily releasable | ||||||
APC: ≥0.3μm(Ea/ft3) | 105 | IEST-RP-CC003.3 | ||||
LPC:≥0.5μm(106/m2 ) | 16 | IEST-RP-CC004.3 |
Cleanroom Environment:
• ISO Class 3 – 8
• Class 1 – 100,000
Shelf Life
• Non-Sterile (Dry) – 3 years from date of manufacture
Products | ||||||||||
Number | Description | Sterile | Packaging | Case | ||||||
Dry wipes | ||||||||||
101040092-01 | 4" x 4" dry | 400 wipes/bag | 20 bags | |||||||
101040093-01 | 7" x 7"dry | 100 wipes/bag | 20 bags | |||||||
101040096-01 | 9" x 9" dry | 150 wipes/bag | 15 bags | |||||||
101040096-10 | 9" x 9"dry, SterileWipe | ★ | 150 wipes/bag | 15 bags |
Notes:
1) Valid product comparisons may only be obtained through side-by-side testing in the same test facility, under similar conditions.
2) The information presented here is applicable to the part numbers shown above, as well as to any product containing the same materials and produced under the same conditions.
3) Size can be customized according to customer requirements.
4) Stacked, Bulk and Folded method can be customized according to customer requirements.
