150pcs 9inch Lint Free Laser Cut Absorbent Cleanroom Wiper Polyester 1009SLE
Description:
Ultrasonic sealed border wipers are subjected to our most rigorous washing and border sealing process for applications requiring maximum particle and fiber retention. The cleanest and best performing choice for your most critical tasks. Lowest levels of particles, fibers, IONs and NVRs for your most critical cleaning needs. Maximum cleanliness and fiber control for ISO 3 – 4 environments.
Material/Structure: 100% Polyester with a Sealed-Edge.
Material | 100% polyester |
Color | White |
Weight | 120g/m2±5g |
Size | 6'' x 6" |
Usage industry | Cleanroom,electronics industry and ect |
Cutting way | Laser cut |
Packing | 100pcs/bag,10bags/ctn |
Laundered method | By 18MΩ ultra clean water |
Logo | Customised logo is available |
Certificate | ROHS,TDS,MSDS |
Technical Data:
Attribute; (units) | Value ** | Test Method | ||||
Basis weight; nominal (g/m2) | 123 | MSD-QI-QS-007 A0 | ||||
Absorbency in water | IEST-RP-CC004.3 | |||||
Intrinsic; (mL/g) | 2.51 | |||||
Extrinsic; (mL/m2) | 308.73 | |||||
Sorptive rate; (seconds) | 1 | IEST-RP-CC004.3 | ||||
Non-volatile residue, NVR | IEST-RP-CC004.3 | |||||
In deionized water; (g/m2) | 0.010 | |||||
In isopropanol; (g/m2) | 0.012 | |||||
Specific ions | IEST-RP-CC004.3 | |||||
Sodium; (ppm) | 0.023 | |||||
Chloride; (ppm) | 0.081 | |||||
Potassium; (ppm) | 0.079 | |||||
Particles, readily releasable | ||||||
APC: ≥0.3μm(Ea/ft3) | 86 | IEST-RP-CC003.3 | ||||
LPC:≥0.5μm(106/m2 ) | 9 | IEST-RP-CC004.3 |
Applications:
The wipes are ideal for wiping the interior of process tools and other equipment as well as for general wiping in environments where contamination control is necessary. Widely used in class 100 cleanroom, electronics, pharmaceutical, chemical industry, semiconductor production line, chips and microprocessor etc
1. It is designed for critical processing applications where the high level of contamination control is required.
2.It is widely used for cleaning in industry of Clean room, Semi-conductor, TFT, LCD, micro-electronics, integrated.
circuit,precision instrument, PCB, SMT, medical, lab and aviation etc.
Features :
1. 18MΩ pure water laundered, clean room class10, 000-10 packing.
2. Soft and no harmful to wiped surface.
3. High efficient absorbency
4. Ultro-low particle and dust generation.Remark: Can be medical used after sterilization or be added with alcohol, IPA solutions and so on.
Benefits:
•Ideal for wiping critical surfaces, equipment, materials, and work surfaces;
•Improve yields thru enhanced consistency and control of critical cleaning;
•Selections compatible with all grades of controlled environments;
•Available pre-saturated with ultra-pure IPA and DIW blends ;
Cleanroom Environment:
• ISO Class 3 – 8
• Class 1 – 100,000
Shelf Life
• Non-Sterile (Dry) – 3 years from date of manufacture
• Non-Sterile (Pre-Wetted) – 2 years from the date of manufacture
• Sterile – 2 years from the date of manufacture
Quality Control
¢ You confirm the sample first, then we will do all order according to samples.
¢ The packing will be water-proof, damp-proof and sealed.
¢ All the materials and products will be inspect by Our QC before/during/after mass production according to ISO 9001:2015.
¢ All the products are inspected by professional QC Staff and professional Testing equipments.
